Manufacturer: BMS Ireland (go to products)

Digital Torque Checker 34-340Nm CT340

Go to Product feedback

CT series testers are dedicated to checking and controlling of all types of mechanical, electronic and slliping type torque wrenches. Solid, compact design and small dimensions allow the tester to be used in the most demanding working conditions
Very high 1% measurement accuracy, ease of use and a menu in english, french, german, spanish and other languages guarantee quick, easy and reliable verification of the torque tools in your possession, protecting against the use of a faulty tool in the production or assembly process.

Go to full description

€1,787.62

Shipping costs are not included in the price.

Quantity

szt.

Shipping time: 10 days

Technical parameters

Adapter size 1/2"
Torque range [N·m] 34-340 N·m
Tolerance ±1% CW/CCW
Length 150 mm
Height 90 mm
Width 150mm
Weight 3.5 kg

Description

CT series testers are ideal for quick and very accurate verification of your torque wrenches, the user can
verify any torque wrench at any time, e.g. at the beginning of work or if they have any suspicions about its accuracy.

The most important advantages of CT series testers:

Very high measurement accuracy - 1% both right and left
Calibration certificate from the manufacturer included with the tester
Compact design and small dimensions
Large, color OLED display
Possibility of quick and very accurate verification of torque wrenches
Testers are supplied in a solid plastic packaging

The specially developed ClickTorque mode makes the testers ideal for employee training - the tester checks
not only the torque value at which the wrench mechanism was activated, but also the maximum torque value
achieved - this allows employees/operators to visualize the effects of applying too much torque as a result of
improper use of torque wrenches during work
Ease of installation means that CT testers can be easily used both in production conditions and in factory
laboratories

The internal memory of the device allows for recording up to 10,000 results that can be downloaded to a PC
using the FRANK software supplied with the tester.
All CT testers can be mounted both vertically and horizontally - depending on the customer's needs.
At the customer's request, it is possible to deliver testers with an additional calibration certificate with PCA
accreditation - in such a case, please contact us by phone or e-mail.
